Water Heater Inner Tank TIG and MIG Circular Seam Welding Machine

Overview

Basic Info.

Model NO.	TX-2
Rated Power	22kVA
Transport Package	Wooden Case
Specification	Customized by needs
Trademark	T-shine
Origin	China
HS Code	8515190090
Production Capacity	100 Sets/Year

Product Description

Material: SS steel, cold/hot rolled sheetWorkpiece thickness:0.5-3mmRated voltage: 380VAC 50HZ
Rated power: 22KVA
Effective length of weld: 3200mm
Effective diameter of weld: 310-800mm
Welding Speed: AdjustableWelding quality: Single-side welding, double-sided forming, the weld surface bright and uniform

Material	SS steel, cold/hot rolled sheet
Workpiece thickness	0.5-3mm
Rated voltage	380VAC 50HZ
Rated power	22KVA
Effective length of weld	3200mm
Effective diameter of weld	310-800mm
Welding Speed	Adjustable
Welding quality	Single-side welding, double-sided forming

Device Configuration:1. Cooling copper strip welding car electrical control system2. Water circulation cooling system 3. Hiwin linear guideway4. AirTAC Pneumatic elements

Water Heater Inner Tank TIG and MIG Circular Seam Welding Machine
